Where flow balancing, flow metering, and shut-off are desirable in one valve.Untitled Circuit 12 : RaceTrackDesigns.

Where a simple solution is needed for proportional or static balanced system with constant speed pumping.

Valves with accessory ports for additional accessories also available. With the addition of a butterfly valve for shut off, the 2-1/2″ to 20″ Metering Station becomes a full functioning QuickSet Manual Balance Valve with memory stop for full accurate flow adjustment.

No straight runs are necessary for normal operation.

The 2-1/2″ to 20″ QuickSet and Metering Stations are equipped with a Quadrant Peizo Ring with four sensing ports for more accurate throat signal. Click here to see a video showing the ceramic disc’s performance. The QuickDisc® valve uses a ceramic disc to control the flow and the QuickSet valves uses a ball to control the flow. Valves are available with multiple end connection options including a union end connections.

The QuickDisc®, QuickSet® and SpeedSet are manual balance valves that include brass venturi inserts for flow measurement and graduated memory stops for flow setting. QuickDisc®, QuickSet®, and SpeedSet Manual Balance Valves and Metering Stations Sizes: 1/2″ – 20″
